Gear Pump with hydraulic relief valve – PV Series

PV Series is our patented Hydraulic Gear Pump with integrated valve solution. Available from 5.0 to 6.2 in3/rot for NPTF THREADS and 82 to 102 cc/rev for BSP Threads.

  • Sensitive Valve
  • Quick Relief
  • Efficient Cylinder Protection
  • Easy to Apply
  • Fast to Mount
Clear

Description

PV Series gear pump with relief valve integrated ranging from 82cc/rot (5.0 in3/rot) to 102cc/rot (6.2 in3/rot) is our patented solution available with NPTF or BSP Threads as you need.

This gear pump can operate at a maximum of 210bar (3000 psi) pressure and also 1800 rpm.

Furthermore it is available with various Flange and Axle options:

  • DIN 5462
  • SAE B (2 and 4 bolts)

Why choose PV Series Gear Pump with relief valve?

• Sensitive Valve
• Quick Relief Valve
• Efficient Cylinder Protection
• Easy to Apply
• Fast to Mount

DISPLACEMENT cc/rot (in3/rot)MAXIMUM OPERATING PRESSURE bar (psi)MAXIMUM CONTINOUS ROTATION rpmDIN 5462 ISO 7653 (EN)SAE B 4 BOLTS (B4)SAE B 2 BOLTS (B2)
82 (5.0)210 (3000)1800PV4S82P1PVB4S82P1PVB2S82P1
102 (6.2)190 (2700)1600PV4S105P1PVB4S105P1PVB2S105P1
DISPLACEMENT in3/rot (gpm at 1000 rpm)MAXIMUM OPERATING PRESSURE bar (psi)MAXIMUM CONTINOUS ROTATION rpmSAE B 4 BOLTS (B4)SAE B 2 BOLTS (B2)
5.0 (22)210 (3000)1800PVB4C22P1PVB2C22P1
6.2 (27)190 (2700)1600PVB4C27P1PVB2C27P1

Additional information

Maximum Operating Pressure bar (psi)

210bar (3000psi), 190bar (2700psi)

Displacement

82 (5.0) cc/rot (in3/rot), 102 (6.2)cc/rot (in3/rot), 5.0 (22) in3/rot(gpm at 1000rpm), 6.2 (27) in3/rot(gpm at 1000rpm)

Threads

BSP Threads, NPTF Threads

Flange and Axle Options

DIN 5642 EN (ISO7653), SAE B B4 (4volts), SAE B B2 (2volts)
