Double Bent Axis Piston Pumps – BID SERIES | 38+37 – 70+66cc/rot

//Double Bent Axis Piston Pumps – BID SERIES | 38+37 – 70+66cc/rot

Double Bent Axis Piston Pumps – BID SERIES | 38+37 – 70+66cc/rot

  • Two oil Outlets
  • Maximum Efficiency
  • Switchable Sense of Rotation
  • Reversible
Clear

Description

Double Bent Axis Piston Pumps – BID Series equiped with two outlets, working  on independent pressure and on independent circuits.

This allows using this pumps to serve two independent oil circuits at the same time.

BID Series – Double Bent Axis Piston Pumps advantages

  • Two oil Outlets
  • Maximum Efficiency
  • Switchable Sense of Rotation
  • Reversible

As a result, with ABER double axis piston pumps  – BID series – you will get the job done better, faster and with 100% reliability.

Flange and Axle Options:

  • DIN
    • 5462
    • 9611 agricultural
    • 9611 interior
  • SAE
    • 4 bolts
    • 2 bolts

Choose the right pump for the job.

DISPLACEMENT cc/rot (in3/rot)DIN 5462 ISO 7653 (EN)DIN 9611 AGRICULTURAL (DA)DIN 9611 INTERIOR (DI)SAE* 4 BOLTS (B4/C4)SAE* 2 BOLTS (B2/C2)
57+28(3.5+1.7)BID57+28PBID57+28PDABID57+28PDIBID57+28PB4BID57+28PB2
38+37(2.3+2.3)BID40+40PBID40+40PDABID40+40PDIBID40+40PB4BID40+40PB2
80+38(4.9+2.3)BID80+40HBID80+40HDABID80+40HDIBID80+40HC4BID80+40HC2
58+60(3.5+3.7)BID55+55HBID55+55HDABID55+55HDIBID55+55HC4BID55+55HC2
DISPLACEMENT cc/rot (in3/rot)DIN 5462 ISO 7653 (EN)DIN 9611 AGRICULTURAL (DA)DIN 9611 INTERIOR (DI)SAE* 4 BOLTS (B4/C4)SAE* 2 BOLTS (B2/C2)
70 + 66 (4.3 + 4.0)BID70+70HBID70+70HDABID70+70HDIBID70+70HC4BID70+70HC2

Additional information

For applications up to

350bar (5000psi), 300bar (4300psi)

Displacement cc/rot (in3/rot)

57 + 28 (3.5+1.7), 38 + 37 (2.3+2.3), 80 + 38 (4.9+2.3), 58 + 60 (3.5+3.7), 70 + 66 (3.5+3.7)

Flange and Axle Options

DIN 5642 EN (ISO7653), DIN 9611 DA ( Agricultural), DIN 9611 DI(Interior), SAE B4/C4(4bolts), SAE B2/C2 (2bolts)
