ZF PTO Power Take Off by ABER
ZF PTO Power Take Off from ABER
ZF PTO Power Take Off from ABER
ZF PTO Power Take Off from ABER

ZF PTO

Request a Quote
SKU: N/A Category: Tags: , , , ,

Description

DOWNLOAD | TECHNICAL DATA SHEETS

The widest range of ZF PTO Power Take Off in the market

ZF Power Take Off from ABER has a wide range of models, suitable for almost every model of ZF gearboxes.

It is available with three different controls:

  • Pneumatic,
  • Mechanic or
  • Vacuum control.

Furthermore the ZF Power Take Off has the simple and the reinforced version, and also available with adapter kit when needed.

POWER TAKE OFF´S

REFERENCEOBSERVATIONGEARBOXRATIOCONTROL
TF4001AMP*-S5-351:1,32PNEUMATIC
TF4001SP*-S5-351:1PNEUMATIC
TF4002AMP*-S5-50 ; S5-90 ; S6-65 ; S6-66 ; S6-70 ; S6-75 ; S6-80 ; S6-90 ; 6S-800 ; 6S-1000 ; 6AS-10001:1,32PNEUMATIC
TF4002SP*-S5-50 ; S5-90 ; S6-65 ; S6-66 ; S6-70 ; S6-75 ; S6-80 ; S6-90 ; 6S-800 ; 6S-1000 ; 6AS-10001:1PNEUMATIC
TF4003AMP*VK4002 + TF4002AMP16-S-130 ; 16-S-160 ; 16-S-190 ; 16-S-220 ; 16-S-112/17,28 ; 8-S-151 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1650 ; (trilobe); 16-S-1650 (OLD)1:1,32PNEUMATIC
TF4003SP*VK4002 + TF4002SP16-S-130 ; 16-S-160 ; 16-S-190 ; 16-S-220 ; 16-S-112/17,28 ; 8-S-151 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1650 ; (trilobe); 16-S-1650 (OLD)1:1PNEUMATIC
TF4004AMP*VK4001 + TF4002AMP8-S-151 ; 12-S-2100 ; 12-S-2300 ; 12-S-2800 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1620 TD ; 16-S-1820 TO ; 16-S-1920 TD ; 16-S-2220 TO/TD ; 16-S-2520 TO ; 8-S-1620 TD ; 8-S-1820 TO ; 8-S-220 TO ; 16-S-2320 TD ; 16-S-2330 TD ; 16-S-2720 TO ; 16-S-2720 TO (Z=14) ; 16-S-1650 (NEW); 16-S-1585 TD1:1,32PNEUMATIC
TF4004SP*VK4001 + TF4002SP8-S-151 ; 12-S-2100 ; 12-S-2300 ; 12-S-2800 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1620 TD ; 16-S-1820 TO ; 16-S-1920 TD ; 16-S-2220 TO/TD ; 16-S-2520 TO ; 8-S-1620 TD ; 8-S-1820 TO ; 8-S-220 TO ; 16-S-2320 TD ; 16-S-2330 TD ; 16-S-2720 TO ; 16-S-2720 TO (Z=14); 16-S-1650 (NEW); 16-S-1585 TD1:1PNEUMATIC
TF4005AMP*VK4005 + TF4002AMP 16-K-130 ; 16-S-112 ; 16-S-150 ; (trilobe) 1:1,32PNEUMATIC
TF4005SP*VK4005 + TF4002SP16-K-130 ; 16-S-112 ; 16-S-150 ; (trilobe)1:1 PNEUMATIC
TF4006AMP*VK4006 + TF4002AMP 16-S-112 A ; 16-S-130 A ; 16-S-160 A ; 16-S-190 A ; 16-S-220 A ; (trilobe) 1:1,32 PNEUMATIC
TF4006SP*VK4006 + TF4002SP16-S-112 A ; 16-S-130 A ; 16-S-160 A ; 16-S-190 A ; 16-S-220 A ; (trilobe)01:01PNEUMATIC
TF4011AMP*VK4007 + TF4002AMP16-S-151 IT ; 16-S-181 IT ; 16-S-221 IT ; 16-S-1621 TD IT ; 16-S-1821 TO IT ; 16-S-1921 TD IT ; 16-S-2221 TD/TO IT ; 16-S-2321 TD IT ; 16-S-2331 TD IT ; 16-S-2521 TO IT ; 16-S-2721 TO IT ; 16-S-2731 TO IT ; (Z=14); 16-S-1585 TD IT1:1,32PNEUMATIC
TF4011SP*VK4007 + TF4002SP16-S-151 IT ; 16-S-181 IT ; 16-S-221 IT ; 16-S-1621 TD IT ; 16-S-1821 TO IT ; 16-S-1921 TD IT ; 16-S-2221 TD/TO IT ; 16-S-2321 TD IT ; 16-S-2331 TD IT ; 16-S-2521 TO IT ; 16-S-2721 TO IT ; 16-S-2731 TO IT ; (Z=14); 16-S-1585 TD IT1:1PNEUMATIC
TF4012AMP*VK4008 + TF4002AMP16-S-251 IT ; 16-S-2720 TO IT ; (Z=14)1:1,32PNEUMATIC
TF4012SP*VK4008 + TF4002SP16-S-251 IT ; 16-S-2720 TO IT ; (Z=14)1:1PNEUMATIC
TF4013AMP*VK4009 + TF4002AMP 16-S-150 IT ; (trilobe) 1:1,32 PNEUMATIC
TF4013SP*VK4009 + TF4002SP16-S-150 IT ; (trilobe)1:1PNEUMATIC
TF4014AMP*-S6-36 ; 6S-850 ; 6S-700 ; 6AS-7001:1,32 PNEUMATIC
TF4014SP*-S6-36 ; 6S-850 ; 6S-700 ; 6AS-7001:1PNEUMATIC
TF4015AMP*VK4015 + TF4002AMP5-90 GP ; 5-92 GP ; 4-120 GP1:1,32PNEUMATIC
TF4015SP*VK4015 + TF4002SP5-90 GP ; 5-92 GP ; 4-120 GP1:1PNEUMATIC
TF4017AMP*VK4017 + TF4002AMP5-110 GP ; 5-111 GP ; 4-150 GP1:1,32PNEUMATIC
TF4017SP*VK4017 + TF4002SP 5-110 GP ; 5-111 GP ; 4-150 GP1:1PNEUMATIC
TF4018AMP*VK4Q18 + TF4002AMP9-S-75/13,16 ; 9-S-75/9,56 (ratio ) 1:1,32PNEUMATIC
TF4018SP*VK4018 + TF4002SP 9-S-75/13,16 ; 9-S-75/9,56 1:11:1PNEUMATIC
TF4019AMP*VK4019 + TF4002AMP9-S-109/10,25 ; 9-S-109/10,24 ; 16-S-109/11,86 ; 16-S-109/13,531:1,32PNEUMATIC
TF4019SP*VK4019 + TF4002SP 9-S-109/10,25 ; 9-S-109/10,24 ;16-S-109/11,86 ; 16-S-109/13,531:1PNEUMATIC
TF4020AMP*VK4020 + TF4002AMP9-S-109/12,92 ; 16-S-109/13,04 ; 16-S-109/13,30 ; 16-S-109/13,42 ; 8-S-1091:1,32PNEUMATIC
TF4020SP*VK4020 + TF4002SP9-S-109/12,92 ; 16-S-109/13,04 ; 16-S-109/13,30 ; 16-S-109/13,42 ; 8-S-1091:1PNEUMATIC
TF4021AMP*VK4021 + TF4002AMP9-S-109/12,91 ; 16-S-109/13,31 ; 16-S-109/13,41 ; 9-S-1110 TO/9,48 ; 9-S-1310 TO/9,481:1,32PNEUMATIC
TF4021SP*VK4021 + TF4002SP9-S-109/12,91 ; 16-S-109/13,31 ; 16-S-109/13,41 ; 9-S-1110 TO/9,48 ; 9-S-1310 TO/9,481:1PNEUMATIC
TF4022AMP*VK4022 + TF4002AMP12-AS-1800 ; 12-AS-2301 ; 16-AS-2601 ; 12-AS-1630 TD ; 12-AS-1930 TD/TO ; 12-AS-2130 TD/TO ; 12-AS-2131 TD ; 12-AS-2140 TD ; 12-AS-2340 TD ; 12-AS-2430 TD ; 12-AS-2540 TD/TO ; 12-AS-2330 TO ; 12-AS-2530 TO ; 12-AS-2740 TO ; 12-AS-2940 TO ; 16-AS-2230 TD ; 16-AS-2601 DD ; 16-AS-2601 OD ; 16-AS-2630 TO1:1,32PNEUMATIC
TF4022SP*VK4022 + TF4002SP12-AS-1800 ; 12-AS-2301 ; 16-AS-2601 ; 12-AS-1630 TD ; 12-AS-1930 TD/TO ; 12-AS-2130 TD/TO ; 12-AS-2131 TD ; 12-AS-2140 TD ; 12-AS-2340 TD ; 12-AS-2430 TD ; 12-AS-2540 TD/TO ; 12-AS-2330 TO ; 12-AS-2530 TO ; 12-AS-2740 TO ; 12-AS-2940 TO ; 16-AS-2230 TD ; 16-AS-2601 DD ; 16-AS-2601 OD ; 16-AS-2630 TO1:1PNEUMATIC
TF4023AMP*VK4023 + TF4002AMP12-AS-1800 IT /1631 TD IT /1931 TD/TO IT /2131 TD/TO IT /2141 TD IT /2301 TD/TO IT /2341 TD IT /2431 TD IT /2331 TO IT /2531 TO IT /2541 TO IT /2741 TO IT /2941 TO IT ; 16-AS-2200 IT /2231 TD IT /2601 TD/TO IT /2631 TO IT1:1,32PNEUMATIC
TF4023SP*VK4023 + TF4002SP12-AS-1800 IT /1631 TD IT /1931 TD/TO IT /2131 TD/TO IT /2141 TD IT /2301 TD/TO IT /2341 TD IT /2431 TD IT /2331 TO IT /2531 TO IT /2541 TO IT /2741 TO IT /2941 TO IT ; 16-AS-2200 IT /2231 TD IT /2601 TD/TO IT /2631 TO IT1:1PNEUMATIC
TF4024P*-S5-42/5,721:1,59PNEUMATIC
TF4026P*-S5-42/4,651:1,59PNEUMATIC
TF4027P*-S5-42/7,551:1,33PNEUMATIC
TF4028P*-S5-42/6,561:1,36PNEUMATIC
TF4029M*-5S-200 ; 5S-270 ; 5S-300 ; 2825.5 ; 2830.51:1,65MECHANIC
TF4029P*-5S-200 ; 5S-270 ; 5S-300 ; 2825.5 ; 2830.51:1,65PNEUMATIC
TF4029V*-5S-200 ; 5S-270 ; 5S-300 ; 2825.5 ; 2830.51:1,65VACUUM
TF4030M*-6S-300 ; 6S-3501:1,58MECHANIC
TF4030P*-6S-300 ; 6S-3501:1,58PNEUMATIC
TF4030V*-6S-300 ; 6S-3501:1,58VACUUM
TF4032M*-6S-380 ; 6AS-380 ; 6S-400 ; 6AS-400 ; 2840.6 (part number 8872643 to 8872644)1:1,55MECHANIC
TF4032P*-6S-380 ; 6AS-380 ; 6S-400 ; 6AS-400 ; 2840.6 (part number 8872643 to 8872644)1:1,55PNEUMATIC
TF4032V*-6S-380 ; 6AS-380 ; 6S-400 ; 6AS-400 ; 2840.6 (part number 8872643 to 8872644)1:1,55VACUUM
TF4033AMP*REINFORCEDS5-50 ; S5-90 ; S6-65 ; S6-66 ; S6-70 ; S6-75 ; S6-80 ; S6-90 ; 6S-800 ; 6S-1000 ; 6AS-10001:1PNEUMATIC
TF4034AMP*REINFORCEDS5-50 ; S5-90 ; S6-65 ; S6-66 ; S6-70 ; S6-75 ; S6-80 ; S6-90 ; 6S-800 ; 6S-1000 ; 6AS-10001:1,73PNEUMATIC
TF4035AMP*REINFORCEDS5-50 ; S5-90 ; S6-65 ; S6-66 ; S6-70 ; S6-75 ; S6-80 ; S6-90 ; 6S-800 ; 6S-1000 ; 6AS-10001:1,56PNEUMATIC
TF4035AMP*REINFORCEDS5-50 ; S5-90 ; S6-65 ; S6-66 ; S6-70 ; S6-75 ; S6-80 ; S6-90 ; 6S-800 ; 6S-1000 ; 6AS-10001:1,35PNEUMATIC
TF4037AMP*REINFORCEDS6-36 ; 6S-850 ; 6S-700 ; 6AS-7001:1,56PNEUMATIC
TF4038AMP*REINFORCEDS6-36 ; 6S-850 ; 6S-700 ; 6AS-7001:1,35PNEUMATIC
TF4039AMP*REINFORCEDS6-36 ; 6S-850 ; 6S-700 ; 6AS-7001:1PNEUMATIC
TF4040AMP*REINFORCEDS6-36 ; 6S-850 ; 6S-700 ; 6AS-7001:1,73PNEUMATIC
TF4041AMP*REINFORCED VK4001 + TF4033AMP8-S-151 ; 12-S-2100 ; 12-S-2300 ; 12-S-2800 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1620 TD ; 16-S-1820 TO ; 16-S-1920 TD ; 16-S-2220 TO/TD ; 16-S-2520 TO ; 8-S-1620 TD ; 8-S-1820 TO ; 8-S-220 TO ; 16-S-2320 TD ; 16-S-2330 TD ; 16-S-2720 TO ; 16-S-2720 TO (Z=14); 16-S-1650 (NEW); 16-S-1585 TD1:1PNEUMATIC
TF4042AMP*REINFORCED VK4002 + TF4033AMP16-S-130 ; 16-S-160 ; 16-S-190 ; 16-S-220 ; 16-S-112/17,28 ; 8-S-151 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1650 ; (trilobe); 16-S-1650 (OLD)1:1PNEUMATIC
TF4043AMP*REINFORCED VK4005 + TF4033AMP16-K-130 ; 16-S-112 ; 16-S-150 ; (trilobe)1:1PNEUMATIC
TF4044AMP*REINFORCED VK4006 + TF4033AMP16-S-112 A ; 16-S-130 A ; 16-S-160 A ; 16-S-190 A ; 16-S-220 A ; (trilobe)1:1PNEUMATIC
TF4045AMP*REINFORCED VK4007 + TF4033AMP16-S-151 IT ; 16-S-181 IT ; 16-S-221 IT ; 16-S-1621 TD IT ; 16-S-1821 TD IT ; 16-S-1921 TD IT ; 16-S-2221 TD/TO IT ; 16-S-2321 TD IT ; 16-S-2331 TD IT ; 16-S-2521 TO IT ; 16-S-2721 TO IT ; 16-S-2731 TO IT (Z=14); 16-S-1585 TD IT1:1PNEUMATIC
TF4046AMP*REINFORCED VK4008 + TF4033AMP16-S251 IT ; 16-S-2720 TO IT (Z=14)1:1PNEUMATIC
TF4047AMP*REINFORCED VK4009 + TF4033AMP16-S-150 IT ; (trilobe)1:1PNEUMATIC
TF4048AMP*REINFORCED VK4015 + TF4033AMP5-90 GP ; 5-92 GP ; 4-120 GP1:1PNEUMATIC
TF4049AMP*REINFORCED VK4016 + TF4033AMP5-110 GPA1:1PNEUMATIC
TF4050AMP*REINFORCED VK4017 + TF4033AMP5-110 GP ; 5-111 GP ; 4-150 GP1:1PNEUMATIC
TF4051AMP*REINFORCED VK4018 + TF4033AMP9-S-75/13,16 ; 9-S-75/9,561:1PNEUMATIC
TF4052AMP*REINFORCED VK4019 + TF4033AMP9-S-109/10,25 ; 9-S-109/10,24 ; 16-S-109/11,86 ; 16-S-109/13,531:1PNEUMATIC
TF4053AMP*REINFORCED VK4020 + TF4033AMP9-S-109/12,92 ; 16-S-109/13,04 ; 16-S-109/13,30 ; 16-S-109/13,42 ; 8-S-1091:1PNEUMATIC
TF4054AMP*REINFORCED VK4021 + TF4033AMP9-S-109/12,91 ; 16-S-109/13,31 ; 16-S-109/13,41 ; 9-S-1110 TO/9,48 ; 9-S-1310 TO/9,481:1PNEUMATIC
TF4055AMP*REINFORCED VK4022 + TF4033AMP12-AS-1800 ; 12-AS-2301 ; 16-AS-2200 ; 12-AS-2601 ; 12-AS-1630 TD ; 12-AS-1930 TD/TO ; 12-AS-2130 TD/TO ; 12-AS-2131 TD ; 12-AS-2140 TD ; 12-AS-2340 TD ; 12-AS-2430 TD ; 12-AS-2540 TD/TO ; 12-AS-2330 TO ; 12-AS-2530 TO ; 12-AS-2740 TO ; 12-AS-2940 TO ; 16-AS-2230 TD ; 16-AS-2601 DD/OD ; 16-AS-2630 TO1:1PNEUMATIC
TF4056AMP*REINFORCED VK4023 + TF4033AMP12-AS-1800 IT ; 12-AS-1631 TD IT ; 12-AS-1931 TD/TO IT ; 12-AS-2131 TD/TO IT ; 12-AS-2141 TD IT ; 12-AS-2301 TD/TO IT ; 12-AS-2341 TD IT ; 12-AS-2431 TD IT ; 12-AS-2331 TO IT ; 12-AS-2531 TO IT ; 12-AS-2541 TO IT ; 12-AS-2740 TO ; 12-AS-2940 TO ; 16-AS-2230 TD ; 16-AS-2601 DD/OD ; 16-AS-2630 TO1:1PNEUMATIC
TF4057AMP*REINFORCED VK4001 + TF4034AMP8-S-151 ; 12-S-2100 ; 12-S-2300 ; 12-S-2800 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1620 TD ; 16-S-1820 TO ; 16-S-1920 TD ; 16-S-2220 TO/TD ; 16-S-2520 TO ; 8-S-1620 TD ; 8-S-1820 TO ; 8-S-220 TO ; 16-S-2320 TD ; 16-S-2330 TD ; 16-S-2720 TO ; 16-S-2720 TO (Z=14); 16-S-1650 (NEW); 16-S-1585 TD1:1,73PNEUMATIC
TF4058AMP*REINFORCED VK4002 + TF4034AMP16-S-130 ; 16-S-160 ; 16-S-190 ; 16-S-220 ; 16-S-112/17,28 ; 8-S-151 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1650 ; (trilobe); 16-S-1650 (OLD)1:1,73PNEUMATIC
TF4059AMP*REINFORCED VK4005 + TF4034AMP16-K-130 ; 16-S-112 ; 16-S-150 ; (trilobe)1:1,73PNEUMATIC
TF4060AMP*REINFORCED VK4006 + TF4034AMP16-S-112 A ; 16-S-130 A ; 16-S-160 A ; 16-S-190 A ; 16-S-220 A ; (trilobe)1:1,73PNEUMATIC
TF4061AMP*REINFORCED VK4007 + TF4034AMP16-S-151 IT ; 16-S-181 IT ; 16-S-221 IT ; 16-S-1621 TD IT ; 16-S-1821 TO IT ; 16-S-1921 TD IT ; 16-S-2221 TD/TO IT ; 16-S-2321 TD IT ; 16-S-2331 TD IT ; 16-S-2521 TO IT ; 16-S-2721 TO IT ; 16-S-2731 TO IT (Z=14); 16-S-1585 TD IT1:1,73PNEUMATIC
TF4062AMP*REINFORCED VK4008 + TF4034AMP16-S251 IT ; 16-S-2720 TO IT (Z=14)1:1,73PNEUMATIC
TF4063AMP*REINFORCED VK4009 + TF4034AMP16-S-150 IT ; (trilobe)1:1,73PNEUMATIC
TF4064AMP*REINFORCED VK4015 + TF4034AMP5-90 GP ; 5-92 GP ; 4-120 GP1:1,73PNEUMATIC
TF4065AMP*REINFORCED VK4016 + TF4034AMP5-110 GPA1:1,73PNEUMATIC
TF4066AMP*REINFORCED VK4017 + TF4034AMP5-110 GP ; 5-111 GP ; 4-150 GP1:1,73PNEUMATIC
TF4067AMP*REINFORCED VK4018 + TF4034AMP9-S-75/13,16 ; 9-S-75/9,561:1,73PNEUMATIC
TF4068AMP*REINFORCED VK4019 + TF4034AMP9-S-109/10,25 ; 9-S-109/10,24 ; 16-S-109/11,86 ; 16-S-109/13,531:1,73PNEUMATIC
TF4069AMP*REINFORCED VK4020 + TF4034AMP9-S-109/12,92 ; 16-S-109/13,04 ; 16-S-109/13,30 ; 16-S-109/13,42 ; 8-S-1091:1,73PNEUMATIC
TF4070AMP*VK4021 + TF4034AMP9-S-109/12,91 ; 16-S-109/13,31 ; 16-S-109/13,41 ; 9-S-1110 TO/9,48 ; 9-S-1310 TO/9,481:1,73PNEUMATIC
TF4071AMP*REINFORCED VK4022 + TF4034AMP12-AS-1800 ; 12-AS-2301 ; 16-AS-2200 ; 12-AS-2601 ; 12-AS-1630 TD ; 12-AS-1930 TD/ TO ; 12-AS-2130 TD/TO ; 12-AS-2131 TD ; 12-AS-2140 TD ; 12-AS-2340 TD ; 12-AS-2430 TD ; 12-AS-2540 TD/TO ; 12-AS-2330 TO ; 12-AS-2530 TO ; 12-AS-2740 TO ; 12-AS-2940 TO ; 16-AS-2230 TD ; 16-AS-2601 DD/OD ; 16-AS-2630 TO1:1,73PNEUMATIC
TF4072AMP*REINFORCED VK4023 + TF4034AMP12-AS-1800 IT ; 12-AS-1631 TD IT ; 12-AS-1931 TD/TO IT ; 12-AS-2131 TD/TO IT ; 12-AS-2141 TD IT ; 12-AS-2301 TD/TO IT ; 12-AS-2141 TD IT ; 12-AS-2331 TO IT ; 12-AS-2531 TO IT ; 12-AS-251 TO IT ; 12-AS-2741 TO IT ; 12-AS-2941 TO IT ; 16-AS-2200 IT ; 16-AS-2231 TD IT ; 16-AS-2601 TD/TO IT ; 16-AS-2631 TO IT1:1,73PNEUMATIC
TF4073AMP*REINFORCERD VK4001 + TF4035AMP8-S-151 ; 12-S-2100 ; 12-S-2300 ; 12-S-2800 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1620 TD ; 16-S-1820 TO ; 16-S-1920 TD ; 16-S-2220 TO/TD ; 16-S-2520 TO ; 8-S-1620 TD ; 8-S-1820 TO ; 8-S-220 TO ; 16-S-2320 TD ; 16-S-2330 TD ; 16-S-2720 TO ; 16-S-2720 TO (Z=14); 16-S-1650 (NEW); 16-S-1585 TD1:1,56PNEUMATIC
TF4074AMP*REINFORCED VK4002 + TF4035AMP16-S-130 ; 16-S-160 ; 16-S-190 ; 16-S-220 ; 16-S-112/17,28 ; 8-S-151 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1650 ; (trilobe); 16-S-1650 (OLD)1:1,56PNEUMATIC
TF4075AMP*REINFORCED VK4005 + TF4035AMP16-K-130 ; 16-S-112 ; 16-S-150 ; (trilobe)1:1,56PNEUMATIC
TF4076AMP*REINFORCED VK4006 + TF4035AMP16-S-112 A ; 16-S-130 A ; 16-S-160 A ; 16-S-190 A ; 16-S-220 A ; (trilobe)1:1,56PNEUMATIC
TF4077AMP*REINFORCED VK4007 + TF4035AMP16-S-151 IT ; 16-S-181 IT ; 16-S-221 IT ; 16-S-1621 TD IT ; 16-S-1821 TO IT ; 16-S-1921 TD IT ; 16-S-2221 TD/TO IT ; 16-S-2321 TD IT ; 16-S-2331 TD IT ; 16-S-2521 TO IT ; 16-S-2721 TO IT ; 16-S-2731 TO IT (Z=14); 16-S-1585 TD IT1:1,56PNEUMATIC
TF4078AMP*REINFORCED VK4008 + TF4035AMP16-S251 IT ; 16-S-2720 TO IT (Z=14)1:1,56PNEUMATIC
TF4079AMP*REINFORCED VK4009 + TF4035AMP16-S-150 IT ; (trilobe)1:1,56PNEUMATIC
TF4080AMP*REINFORCED VK4015 + TF4035AMP5-90 GP ; 5-92 GP ; 4-120 GP1:1,56PNEUMATIC
TF4081AMP*REINFORCED VK4016 + TF4035AMP5-110 GPA1:1,56PNEUMATIC
TF4082AMP*REINFORCED VK4017 + TF4035AMP5-110 GP ; 5-111 GP ; 4-150 GP1:1,56PNEUMATIC
TF4083AMP*REINFORCED VK4018 + TF4035AMP9-S-75/13,16 ; 9-S-75/9,561:1,56PNEUMATIC
TF4084AMP*REINFORCED VK4019 + TF4035AMP9-S-109/10,25 ; 9-S-109/10,24 ; 16-S-109/11,86 ; 16-S-109/13,531:1,56PNEUMATIC
TF4085AMP*REINFORCED VK4020 + TF4035AMP9-S-109/12,92 ; 16-S-109/13,04 ; 16-S-109/13,30 ; 16-S-109/13,42 ; 8-S-1091:1,56PNEUMATIC
TF4086AMP*REINFORCED VK4021 + TF4039-S-109/12,91 ; 16-S-109/13,31 ; 16-S-109/13,41 ; 9-S-1110 TO/9,48 ; 9-S-1310 TO/9,481:1,56PNEUMATIC
TF4087AMP*REINFORCED VK4022 + TF4035AMP12-AS-1800 ; 12-AS-2301 ; 16-AS-2200 ; 12-AS-2601 ; 12-AS-1630 TD ; 12-AS-1930 TD/TO ; 12-AS-2130 TD/TO ; 12-AS-2131 TD ; 12-AS-2140 TD ; 12-AS-2340 TD ; 12- AS-2430 TD ; 12-AS-2540 TD/TO ; 12-AS-2330 TO ; 12-AS-2530 TO ; 12-AS-2740 TO ; 12-AS-2940 TO ; 16-AS-2230 TD ; 16-AS-2601 DD/OD ; 16-AS-2630 TO1:1,56PNEUMATIC
TF4088AMP*REINFORCED VK4023 + TF4035AMP12-AS-1800 IT ; 12-AS-1631 TD IT ; 12-AS-1931 TD/TO IT ; 12-AS-2131 TD/TO IT ; 12-AS-2141 TD IT ; 12-AS-2301 TD/TO IT ; 12-AS-2341 TD IT ; 12-AS-2431 TD IT ; 12-AS-2331 TO IT ; 12-AS-2531 TO IT ; 12-AS-2541 TO IT ; 12-AS-2741 TO IT ; 12-AS-2941 TO IT ; 16-AS-2200 IT ; 16-AS-2231 TD IT ; 16-AS-2601 TD/TO IT ; 16-AS-2631 TO IT1:1,56PNEUMATIC
TF4089AMP*REINFORCED VK4001 + TF4036AMP8-S-151 ; 12-S-2100 ; 12-S-2300 ; 12-S-2800 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1620 TD ; 16-S-1820 TO ; 16-S-1920 TD ; 16-S-2220 TO/TD ; 16-S-2520 TO ; 8-S-1620 TD ; 8-S-1820 TO ; 8-S-220 TO ; 16-S-2320 TD ; 16-S-2330 TD ; 16-S-2720 TO ; 16-S-2730 TO (Z=14); 16-S-1585 TD1:1,35PNEUMATIC
TF4090AMP*REINFORCED VK4002 + TF4036AMP16-S-130 ; 16-S-160 ; 16-S-190 ; 16-S-220 ; 16-S-112/17,28 ; 8-S-151 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1650 ; (trilobe)1:1,35PNEUMATIC
TF4091AMP*REINFORCED VK4005 + TF4036AMP16-K-130 ; 16-S-112 ; 16-S-150 ; (trilobe)1:1,35PNEUMATIC
TF4092AMP*REINFORCED VK4006 + TF4036AMP16-S-112 A ; 16-S-130 A ; 16-S-160 A ; 16-S-190 A ; 16-S-220 A ; (trilobe)1:1,35PNEUMATIC
TF4093AMP*REINFORCED VK4007 + TF4036AMP16-S-151 IT ; 16-S-181 IT ; 16-S-221 IT ; 16-S-1621 TD IT ; 16-S-1821 TD IT ; 16-S-1921 TD IT ; 16-S-2221 TD/TO IT ; 16-S-2321 TD IT ; 16-S-2331 TD IT ; 16-S-2521 TO IT ; 16-S-2721 TO IT ; 16-S-2731 TO IT (Z=14); 16-S-1585 TD IT1:1,35PNEUMATIC
TF4094AMP*REINFORCED VK4008 + TF4036AMP16-S251 IT ; 16-S-2720 TO IT (Z=14)1:1,35PNEUMATIC
TF4095AMP*REINFORCED VK4009 + TF4036AMP16-S-150 IT ; (trilobe)1:1,35PNEUMATIC
TF4096AMP*REINFORCED VK4015 + TF4036AMP16-S-150 IT ; (trilobe)1:1,35PNEUMATIC
TF4097AMP*REINFORCED VK4016 + TF4036AMP5-110 GPA1:1,35PNEUMATIC
TF4098AMP*REINFORCED VK4017 + TF4036AMP5-110 GP ; 5-111 GP ; 4-150 GP1:1,35PNEUMATIC
TF4099AMP*REINFORCED VK4018 + TF4036AMP9-S-75/13,16 ; 9-S-75/9,561:1,35PNEUMATIC
TF4100AMP*REINFORCED VK4019 + TF4036AMP9-S-109/10,25 ; 9-S-109/10,24 ; 16-S-109/11,86 ; 16-S-109/13,531:1,35PNEUMATIC
TF4101AMP*REINFORCED VK4020 + TF4036AMP9-S-109/12,92 ; 16-S-109/13,04 ; 16-S-109/13,30 ; 16-S-109/13,42 ; 8-S-1091:1,35PNEUMATIC
TF4102AMP*REINFORCED VK4021 + TF4036AMP9-S-109/12,91 ; 16-S-109/13,31 ; 16-S-109/13,41 ; 9-S-1110 TO/9,48 ; 9-S-1310 TO/9,481:1,35PNEUMATIC
TF4103AMP*REINFORCED VK4022 + TF4036AMP12-AS-1800 ; 12-AS-2301 ; 16-AS-2200 ; 12-AS-2601 ; 12-AS-1630 TD ; 12-AS-1930 TD/TO ; 12-AS-2130 TD/TO ; 12-AS-2131 TD ; 12-AS-2140 TD ; 12-AS-2340 TD ; 12-AS-2430 TD ; 12-AS-2540 TD/TO ; 12-AS-2330 TO ; 12-AS-2530 TO ; 12-AS-2740 TO ; 12-AS-2940 TO ; 16-AS-2230 TD ; 16-AS-2601 DD/OD ; 16-AS-2630 TO1:1,35PNEUMATIC
TF4104AMP*REINFORCED VK4023 + TF4036AMP12-AS-1800 IT ; 12-AS-1631 TD IT ; 12-AS-1931 TD/TO IT ; 12-AS-2131 TD/TO IT ; 12-AS-2141 TD IT ; 12-AS-2301 TD/TO IT ; 12-AS-2141 TD IT ; 12-AS-2331 TO IT ; 12-AS-2531 TO IT ; 12-AS-251 TO IT ; 12-AS-2741 TO IT ; 12-AS-2941 TO IT ; 16-AS-2200 IT ; 16-AS-2231 TD IT ; 16-AS-2601 TD/TO IT ; 16-AS-2631 TO IT1:1,35PNEUMATIC
TF4105M*-6S-420/5,152 ; MO37S6 (left side assembly)1:1,39MECHANIC
TF4105P*-6S-420/5,152 ; MO37S6 (left side assembly)1:1,39PNEUMATIC
TF4105V*-6S-420/5,152 ; MO37S6 (left side assembly)1:1,39VACUUM

ADAPTER KITS

REFERENCEOBSERVATIONGEARBOXRATIOCONTROL
VK4001-8-S-151 ; 12-S-2100 ; 12-S-2300 ; 12-S-2800 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1620 TD ; 16-S-1820 TO ; 16-S-1920 TD ; 16-S-2220 TO/TD ; 16-S-2520 TO ; 8-S-1620 TD ; 8-S-1820 TO ; 8-S-220 TO ; 16-S-2320 TD ; 16-S-2330 TD ; 16-S-2720 TO ; 16-S-2720 TO (Z=14) ; 16-S-1650 (NEW); 16-S-1585 TD--
VK4002-16-S-130 ; 16-S-160 ; 16-S-190 ; 16-S-220 ; 16-S-112/17,28 ; 8-S-151 ; 16-S-151 ; 16-S-181 ; 16-S-221 ; 16-S-1650 ; (trilobe) ; 16-S-1650 (OLD)--
VK4005-16-K-130 ; 16-S-112 ; 16-S-150 ; (trilobe)--
VK4006-16-S-112 A ; 16-S-130 A ; 16-S-160 A ; 16-S-190 A ; 16-S-220 A ; (trilobe)--
VK4007-16-S-151 IT ; 16-S-181 IT ; 16-S-221 IT ; 16-S-1621 TD IT ; 16-S-1821 TO IT ; 16-S-1921 TD IT ; 16-S-2221 TD/TO IT ; 16-S-2321 TD IT ; 16-S-2331 TD IT ; 16-S-2521 TO IT ; 16-S-2721 TO IT ; 16-S-2731 TO IT ; (Z=14); 16-S-1585 TD IT--
VK4008-16-S-251 IT ; 16-S-2720 TO IT ; (Z=14)--
VK4009-16-S-150 IT ; (trilobe)--
VK4015-5 - 90 GP ; 5 - 92 GP ; 4 - 120 GP--
VK4016-5 - 110 GPA--
VK4017-5 - 110 GP ; 5 - 111 GP ; 4 - 150 GP--
VK4018-9-S-75/13,16 ; 9-S-75/9,56--
VK4019-9-S-109/10,25 ; 9-S-109/10,24 ; 16-S-109/11,86 ; 16-S-109/13,53--
VK4020-9-S-109/12,92 ; 16-S-109/13,04 ; 16-S-109/13,30 ; 16-S-109/13,42 ; 8-S-109--
VK4021-9-S-109/12,91 ; 16-S-109/13,31 ; 16-S-109/13,41 ; 9-S-1110 TO/9,48 ; 9-S-1310 TO/9,48--
VK4022-12-AS-1600 ; 12-AS-2301 ; 16-AS-2200 ; 16-AS-2601 ; 12-AS-1630 TD ; 12-AS-1930 TD/TO ; 12-AS-2130 TD/TO ; 12-AS-2131 TD ; 12-AS-2140 TD ; 12-AS-2340 TD ; 12-AS-2430 TD ; 12-AS-2540 TD ; 12-AS-2330 TO ; 12-AS-2530 TO ; 12-AS-2540 TO ; 12-AS-2740 TO ; 12-AS-2940 TO ; 16-AS-2230 TD ; 16-AS-2601 DD/OD ; 16-AS-2630 TO--
VK4023-12-AS-1800 IT ; 12-AS-1631 TD IT ; 12-AS-1931 TD/TO IT ; 12-AS-2131 TD/TO IT ; 12-AS-211 TD IT ; 12-AS-2301 TD/TO IT ; 12-AS-2341 TD IT ; 12-AS-2431 TD IT ; 12-AS-2331TO IT ; 12-AS-2531 TO IT ; 12-AS-2541 TO IT ; 12-AS-2741 TO IT ; 12-AS-2941 TO IT ; 16-AS-2200 IT ; 16-AS-2231 TD IT ; 16-AS-2601 TD/TO IT ; 16-AS-2631 TO IT--
VK4025-12AS-1010 TD/TO; 12AS-1210TO--
VK4026-12AS-1420 TD/TO; 12AS-1620 TO--
VK4028AM-12-AS-1630 TD; 12-AS-1930 TD; 12-AS-2130 TD; 12-AS-2140 TD; 12-AS-2330 TD; 12-AS-2340 TD; 12-AS-2430 TD; 12-AS-2540 TD; 12-AS-1631 TD IT; 12-AS-1931 TD IT; 12-AS-2131 TD IT; 12-AS-2141 TD IT; 12-AS-2301 TD IT; 12-AS-2331 TD; 12-AS-2341 TD IT; 12-AS-2431 TD IT; 12-AS-1800; 12-AS-1800 IT; 12-AS-1930 TO; 12-AS-2130 TO; 12-AS-2330 TO; 12-AS-2530 TO; 12-AS-1931 TO IT; 12-AS-2131 TO IT; 12-AS-2301 TO IT; 12-AS-2331 TO IT; 12-AS-2531 TO IT; 12-AS-2540 TO; 12-AS-2740 TO; 12-AS-2940 TO; 12-AS-2541 TO IT; 12-AS-2741 TO IT; 12-AS-2941 TO IT; 12-AS-3141 TO IT; 16-AS-2200; 16-AS-2200 IT; 16-AS-2230 TD; 16-AS-2601 TD 16-AS-2231 TD IT; 16-AS-2601 TD IT; 16-AS-2601 TO; 16-AS-2630 TO; 16-AS-2601 TO IT; 16-AS-2631 TO IT;--
VK4028S-12-AS-1630 TD; 12-AS-1930 TD; 12-AS-2130 TD; 12-AS-2140 TD; 12-AS-2330 TD; 12-AS-2340 TD; 12-AS-2430 TD; 12-AS-2540 TD; 12-AS-1631 TD IT; 12-AS-1931 TD IT; 12-AS-2131 TD IT; 12-AS-2141 TD IT; 12-AS-2301 TD IT; 12-AS-2331 TD; 12-AS-2341 TD IT; 12-AS-2431 TD IT; 12-AS-1800; 12-AS-1800 IT; 12-AS-1930 TO; 12-AS-2130 TO; 12-AS-2330 TO; 12-AS-2530 TO; 12-AS-1931 TO IT; 12-AS-2131 TO IT; 12-AS-2301 TO IT; 12-AS-2331 TO IT; 12-AS-2531 TO IT; 12-AS-2540 TO; 12-AS-2740 TO; 12-AS-2940 TO; 12-AS-2541 TO IT; 12-AS-2741 TO IT; 12-AS-2941 TO IT; 12-AS-3141 TO IT; 16-AS-2200; 16-AS-2200 IT; 16-AS-2230 TD; 16-AS-2601 TD 16-AS-2231 TD IT; 16-AS-2601 TD IT; 16-AS-2601 TO; 16-AS-2630 TO; 16-AS-2601 TO IT; 16-AS-2631 TO IT;--
VK4027-12-AS-2131 IT3 ; 12-AS-2541 IT3 ; 12-AS-2741 IT3--
VK402912-TX-1410 TD; 12-TX-1610 TD; 12-TX-1810 TD 12-TX-1411 TD IT; 12-TX-1611 TD IT; 12-TX-1811 TD IT 12-TX-2010 TD; 12-TX-2210 TD 12-TX-2420 TD; 12-TX-2620 TD; 12-TX-2820 TD 12-TX-1610 TO; 12-TX-1810 TO; 12-TX-2010 TO 12-TX-1611 TO IT; 12-TX-1811 TO IT; 12-TX-2011 TO IT 12-TX-2210 TO; 12-TX-2410 TO; 12-TX-2610 TO 12-TX-2820 TO; 12-TX-3020 TO; 12-TX-3220 TO; 12-TX-3420 TO 16-TX-1640 TD; 16-TX-1840 TD; 16-TX-2040 TD 16-TX-1641 TD IT; 16-TX-1841 TD IT; 16-TX-2041 TD IT 16-TX-2240 TD; 16-TX-2440 TD; 16-TX-2640 TD 16-TX-2840 TD 16-TX-1840 TO; 16-TX-2040 TO; 16-TX-2240 TO 16-TX-1841 TO IT; 16-TX-2041 TO IT; 16-TX-2241 TO IT 16-TX-2440 TO; 16-TX-2640 TO; 16-TX-2840 TO 16-TX-3040 TO; 16-TX-3240 TO; 16-TX-3440 TO

* Also available with electric/mechanic sensor ON/OFF
